Overview

Product family features

• Wireless 5-channel dimmer, with output voltage of 12, 24 and 48 V

• Control of LED modules up to 12 A

• Wireless module based on Bluetooth Low Energy

Product family benefits

• Control of white, Tunable White, RGB, RGBW and RGBTW LED modules

• Independent housing for ceiling installation

• Support of systems based on CASAMBI lighting control solutions

• Minimal installation effort

• Dry contacts for optional connection to any commercial pushbutton

Areas of application

• Suitable for indoor installations

• Shops and hospitality: retail, hotels, restaurants

• Museums, residential buildings

Ecodesign regulation information:

Intended for use with LED modules.

The forward voltage of the LED light source shall be within the defined operating window of the control gear in all operating conditions including dimming if applicable.

Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
