Overview

Product family features

• Qualified Bluetooth mesh enabled by Silvair

• Works with OSRAM Hubsense

• Supply voltage: 220…240 V

• Line frequency: 0 Hz | 50 Hz | 60 Hz

• Line voltage: 198…264 V

• Lifetime: up to 100,000 h

• Type of protection: IP20

Product family benefits

• High quality of light thanks to low output ripple current

• Short housing for minimum distance between spotlights

• Versatile QBM window driver due to flexible output characteristic

• Easy and fast output current setting via NFC

• High-quality dimming of 1…100 % by amplitude dimming

• SELV system

Areas of application

• Track lights

• Shops and hospitality: retail, hotels, restaurants

Ecodesign regulation information:

Intended for use with LED modules.

The forward voltage of the LED light source shall be within the defined operating window of the control gear in all operating conditions including dimming if applicable.

Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
